EN10028-3 P355NL1 for reactor

The P355NL1 steel plate is a low-alloy high-strength structural steel compliant with European standards, mainly used for manufacturing pressure-bearing equipment, low-temperature pressure vessels, pipelines, and other devices.

Chat Now

Send Inquiry

Product Description

EN10028-3 P355NL1 for reactor

The EN10028-3 P355NL1 steel plate is a low-alloy high-strength structural steel compliant with European standards, mainly used for manufacturing pressure-bearing equipment, low-temperature pressure vessels, pipelines, and other devices.

Naming Convention:

“P” denotes European standard vessel steel plate, indicating compliance with European standards.
“355” signifies that the yield strength of the steel plate is not less than 355 MPa.
“N” indicates the delivery condition as normalized. Normalization is a heat treatment process that improves the microstructure and properties of the steel plate.
“L1” designates the steel plate as a low-temperature quality grade, enabling it to maintain good performance in low-temperature environments without easy brittle fracture.

Implementation Standard:P355NL1 steel plates are produced in accordance with the European standard EN 10028-3.

Dimensional Specifications :Thickness: 8MM to 150MM Width: 1600mm to 2500mm Length: 6000mm to 12000mm

1.What are the chemical composition and mechanical property of P355NL1 for reactor?

P355NL1 Chemical Composition
Grade	The Element Max(%)
Grade	C	Si	Mn	P	S	Al(min)	N
P355NL1	0.18	0.50	0.9-1.70	0.03	0.020		0.02
	Cr	Cu	Mo	Nb	Ni	T	V
	0.30	0.30	0.08	0.005	0.50	0.03	0.10

Grade		P355NL1 Mechanical Property
Grade	Thickness	Yield	Tensilmie	Elongation	Impact Energy(KV J)min
P355NL1	mm	Min Mpa	Mpa	Min %	-20°	0°	+20°
	≤ 16	355	490-630	22	47	55	63
	16> to ≤35	355	490-630	22	47	55	63
	35> to ≤50	345	490-630	22	47	55	63
	50>to s70	325	490-630	22	47	55	63
	70> to ≤100	315	470-610	21	47	55	63
	100>to ≤150	295	450-590	21	47	55	63

2.What are the performance advantages of EN10028-3 P355NL1 for reactor?

High strength: The yield strength of P355NL1 steel plate is usually about 355 MPa, and the tensile strength is higher. This enables it to withstand large pressure and temperature changes, ensuring the stability and safety of the structure.
Excellent toughness: P355NL1 steel plate can still maintain good toughness in low-temperature environments, and is not prone to brittle fracture. This feature gives it obvious advantages in applications under low-temperature conditions.
Corrosion resistance: P355NL1 steel plate has excellent corrosion resistance and can adapt to various corrosive environments. Alloying elements such as chromium (Cr) and nickel (Ni) in its chemical composition play a key role in improving corrosion resistance.
Good weldability: P355NL1 steel plate is easy to weld, with high strength and good airtightness of the welded joints. This allows for convenient cutting, bending, drilling and other processing operations during manufacturing, while ensuring the quality and performance of the welded joints.

3.What are the typical applications of EN10028-3 P355NL1 for reactor?

Oil and gas industry: Used for manufacturing storage tanks, pipelines, oil refining equipment, etc.
Chemical industry: Used for manufacturing reactors, heat exchangers, boilers and other equipment.
Power industry: Used for manufacturing steam turbines, boiler drums and other equipment.
Other industries: Also applied in construction, nuclear energy, shipbuilding and other industries.
