P460M Hot rolled fine grain steel for pressure vessels

P460M is thermomechanically rolled steel for pressure vessels and boilers. The “P” stands for pressure, “460” is the minimum yield strength in MPa, and “M” means thermomechanical processing.

Chat Now

Send Inquiry

Product Description

P460M is thermomechanically rolled steel for pressure vessels and boilers.

The “P” stands for pressure, “460” is the minimum yield strength in MPa, and “M” means thermomechanical processing.

Normative standard: EN 10028-5.

It has good weldability, high strength, and toughness.

P460M is used for industrial tanks and pressure equipment under high temperatures and pressures.

What is P460M？

P460M is a pressure vessel steel made of 0.20% carbon and 1.40% manganese, produced in solid plate form. It is a thermomechanically rolled fine-grain steel with high strength, good weldability, and toughness. Used mainly in pressure vessels and boilers under high temperatures and pressures, it also comes in variants like P460ML1 and P460ML2 for better low-temperature performance. P460M is a thermomechanically rolled and weldable fine-grain steel.

Why Choose P460M Pressure Vessel Steel?

Looking for reliable steel for high-pressure applications like tanks or boilers? At Steel Pro Group, we recommend P460M for its high strength, excellent weldability, and toughness in extreme conditions. P460M is easy to work with, saving time and costs while offering consistent quality with fewer defects. Choosing us ensures reliable supply and expert support throughout your project. What makes P460M stand out is its balance of strength and weldability. For lower-temperature needs, alternatives like P460ML1 or P355NH can also be considered. With P460M, you get dependable, long-lasting performance for your pressure equipment.

Product Specification

Category	Details
Quality Standard	EN 10028-5
Certifications	ISO 9001, CE, AD 2000-W0, PED, ASME Section II, LR, DNV, BV, SGS
Thickness	6-100mm
Width	900-4800mm
Length	3000-25000mm
Weight	Depends on length and width
Tolerances	Thickness: ±0.3mm to ±0.5mm, Width: ±10mm, Length: ±15mm
Technology	Thermomechanical Rolling,
Processing Service	Bending, Welding, Decoiling, Cutting, Punching
Shapes	Pressure Vessel Steel Plate, Pressure Vessel Steel Sheet, Pipes, Profiles
MOQ (Minimum Order Quantity)	5 tons (according to the actual tonnage)
Lead Time	Typically 7-20 days
Price Terms & Payment	Based on customer requirements, T/T, L/C
Ports	Qingdao, Lianyungang, Dalian
Export Countries	Southeast Asia, Central Asia, Europe, Russia, South America, Middle East, etc.
Shipping Method	Offers Sea, Air and Customized Shipping

Chemical Compositions

Element	P460M (%)	P460ML1 (%)	P460ML2 (%)


Carbon, C	≤ 0.20	≤ 0.18	≤ 0.18
Manganese, Mn	1.10-1.70	1.10-1.70	1.10-1.70
Silicon, Si	≤ 0.50	≤ 0.50	≤ 0.50
Phosphorus, P	≤ 0.025	≤ 0.025	≤ 0.025
Sulfur, S	≤ 0.015	≤ 0.015	≤ 0.015
Chromium, Cr	≤ 0.30	≤ 0.30	≤ 0.30
Nickel, Ni	≤ 0.80	≤ 0.80	≤ 0.80
Copper, Cu	≤ 0.30	≤ 0.30	≤ 0.30
Molybdenum, Mo	≤ 0.08	≤ 0.08	≤ 0.08
Vanadium, V	≤ 0.06	≤ 0.06	≤ 0.06
Niobium, Nb	≤ 0.05	≤ 0.05	≤ 0.05
Titanium, Ti	≤ 0.03	≤ 0.03	≤ 0.03

Mechanical Properties

Property	P460M	P460ML1	P460ML2


Tensile Strength (MPa / psi)	580-730 MPa / 84,122-105,846 psi	570-720 MPa / 82,663-104,427 psi	570-720 MPa / 82,663-104,427 psi
Yield Strength (MPa / psi)	≥ 460 MPa / 66,717 psi	≥ 460 MPa / 66,717 psi	≥ 460 MPa / 66,717 psi
Brinell Hardness (HB)	130-175 HB	130-175 HB	130-175 HB
Rockwell Hardness (HRB)	70-85 HRB	70-85 HRB	70-85 HRB
Vickers Hardness (HV)	130-175 HV	130-175 HV	130-175 HV
Elongation (%)	≥ 17%	≥ 19%	≥ 19%
Elastic Modulus (GPa / psi)	210 GPa / 30.5 x 10^6 psi	210 GPa / 30.5 x 10^6 psi	210 GPa / 30.5 x 10^6 psi

Data After TM Rolling Processing

Property	P460M (TMCP)	P460ML1 (TMCP)	P460ML2 (TMCP)


Tensile Strength (MPa / psi)	580-730 MPa / 84,122-105,846 psi	570-720 MPa / 82,663-104,427 psi	570-720 MPa / 82,663-104,427 psi
Yield Strength (MPa / psi)	≥ 460 MPa / 66,717 psi	≥ 460 MPa / 66,717 psi	≥ 460 MPa / 66,717 psi
Brinell Hardness (HB)	130-175 HB	130-175 HB	130-175 HB
Rockwell Hardness (HRB)	70-85 HRB	70-85 HRB	70-85 HRB
Vickers Hardness (HV)	130-175 HV	130-175 HV	130-175 HV
Elongation (%)	Increased to ≥ 19%	Increased to ≥ 21%	Increased to ≥ 21%
Elastic Modulus (GPa / psi)	210 GPa / 30.5 x 10^6 psi	210 GPa / 30.5 x 10^6 psi	210 GPa / 30.5 x 10^6 psi

Industries & Applications

Industries	Products


Pressure Vessels	Storage Tanks, Heat Exchangers, Gas Cylinders, Boilers, Autoclaves
Energy Sector	Wind Towers, Offshore Platforms, Oil Storage Tanks, Power Plant Boilers, Steam Generators
Petrochemical Plants	Reactor Vessels, Fractionating Towers, Process Columns, Oil Refinery Tanks, Heat Exchangers
Shipbuilding	Ship Hulls, Ballast Tanks, Marine Boilers, Deck Structures, Offshore Equipment
Chemical Industry	Chemical Storage Tanks, Reactors, Pressure Reactors, Gas Separators, Distillation Columns
Construction	Heavy-Duty Bridges, Large Cranes, Load-Bearing Beams, Structural Columns, Support Towers
Nuclear Industry	Reactor Containment Vessels, Steam Generators, Cooling System Tanks, Pressure Piping, Fuel Storage Tanks
Mining Equipment	Mining Excavators, Dump Trucks, Pressure Housings, Slurry Tanks, Crushing Machines
Renewable Energy	Biomass Boilers, Solar Power Plants, Geothermal Tanks, Wind Turbine Towers, Hydro Power Plant Equipment

Packing

At SteelPRO Group, we prioritize secure and efficient packing for P460M to ensure it arrives in top condition. Here are four key advantages of our packing process:

Durable protection: We use heavy-duty steel strapping and edge protectors to prevent damage during handling and transport.
Moisture resistance: P460M plates are wrapped with waterproof materials to avoid moisture-related issues like corrosion during long-distance shipping.
Customizable packing: Our packing solutions are tailored to meet specific customer requirements, ensuring the steel is packed for safe transit based on the destination and conditions.
Compliance with international standards: We follow strict international packing regulations to guarantee safe transport, especially when shipping large or high-weight steel plates.

Our process ensures your P460M arrives safely, ready for immediate use.

Machining

P460M Heat Treatment Product Options

At SteelPRO Group, we offer P460M pressure vessel steel in various heat-treated forms to meet different application needs:

Normalized P460M: This version provides improved mechanical properties and uniformity, making it ideal for high-temperature environments.
Thermomechanically Rolled P460M: Enhanced toughness and strength due to the fine-grain structure, suitable for pressure vessels under extreme conditions.
Quenched and Tempered P460M: Offers higher strength and toughness, typically used in more demanding pressure vessel applications.
As-Rolled P460M: Available without additional heat treatment, suitable for standard applications where specific heat treatment is not required.

We also offer customized forms to suit your exact project requirements, ensuring the steel meets both technical and operational needs.

P460M Surface Finish

Shot Blasting: Removes surface contaminants and prepares the steel for further treatment or coating.
Galvanizing: Provides a protective zinc coating to enhance corrosion resistance, extending the service life.
Painting: Applies protective paint to prevent corrosion and improve aesthetics, suitable for various environmental conditions.
Pickling: Cleans the surface by removing rust and scale, ensuring better adhesion for coatings.
Powder Coating: Offers a durable, high-quality finish that improves corrosion resistance and is available in various colors.
Sandblasting: Creates a rough surface profile to improve the bond of subsequent coatings and treatments.

If you want to learn about or purchase other pressure vessel steel plates from GNEE, you can send an email to [email protected]. We will be very happy to serve you.
