16Mo3 for LPG Storage Tank Steel Plate

DIN 17155 16Mo3 refers to a specific steel grade used for pressure vessels and boilers, particularly those operating at elevated temperatures. It's a molybdenum-alloyed steel with a minimum 0.3% molybdenum content, enhancing its resistance to oxidation and high temperatures. While DIN 17155 is an older German standard, it's still used for cross-referencing purposes, with EN 10028 now being the current European standard.

Chat Now

Send Inquiry

Product Description

1.What are the chemical composition of DIN 17155 16Mo3 for LPG Storage Tank Steel Plate?

Element	Content (wt%)	Role in the Material
Carbon (C)	0.12–0.20%	Provides basic strength and hardness.
Manganese (Mn)	0.40–0.80%	Improves hardenability and strength.
Silicon (Si)	0.10–0.35%	Enhances resistance to oxidation.
Molybdenum (Mo)	0.25–0.35%	Critical for high-temperature creep resistance.
Phosphorus (P)	≤0.035%	Controlled to minimize brittleness.
Sulfur (S)	≤0.030%	Reduces hot shortness and improves ductility.

2.What is the difference between DIN17155 16Mo3 and P265GH?

Standards & Classification

16Mo3	P265GH
DIN 17155 (obsolete German standard for pressure vessel steel).	EN 10028-2 (current European standard for pressure vessel steel).
Alloy steel (contains 0.25–0.35% Mo for high-temperature strength).	Non-alloy quality steel (low alloy content; primarily C, Mn, Si).

Mechanical Properties

Property	16Mo3 (≤16 mm)	P265GH (≤16 mm)	Key Difference
Yield Strength (ReH)	≥290 MPa	≥265 MPa	16Mo3 has higher yield strength.
Tensile Strength (Rm)	480–630 MPa	430–580 MPa	16Mo3 has higher tensile strength.
Elongation (A5)	≥20%	≥22%	P265GH has better ductility.
Impact Energy (20°C)	≥34 J	≥27 J	16Mo3 has slightly higher toughness.
