ASTM A517/A517M

The ASTM A517/A517M specification is the Standard Specification for Pressure Vessel Plates, Alloy Steel, High-Strength, Quenched and Tempered material used in the application of fusion welded boilers and pressure vessels. ASTM A517/A517M includes A517 Grade B, A517 Grade E, etc.

Chat Now

Send Inquiry

Product Description

1.What are the chemical compositions and mechanical properties of ASTM A517/A517M?

ASTM A517/A517M Chemical Properties
Grade	Carbon	Manganese	Phosphorus,maxA	Sulfur,maxA	Silicon	Nickel	Chromium	Molybdenum	Boron	Vanadium	Titanium	Zirconium	copper	Columbium.max
Grade A	0.13- 0.23	0.74-1.20	0.025	0.025	0.34- 0.86	–	0.46-0.84	0.15-0.31	0.0025 max		–	0.05-0.15	–	–
Grade B	0.13- 0.23	0.64-1.10	0.025	0.025	0.13- 0.37	–	0.36-0.69	0.12-0.28	0.0005- 0.005	0.02-0.09	0.01-0.05	–	–	–
Grade E	0.10- 0.22	0.35-0.78	0.025	0.025	0.08- 0.45	–	1.34-2.06	0.36-0.64	0.001- 0.005	–	0.005-0.11	–	–	–
Grade E	0.08- 0.22	0.55-1.10	0.025	0.025	0.13- 0.37	0.67- 1.03	0.36-0.69	0.36-0.64	0.0005- 0.006	0.02-0.09	0.11max	–	0.15-0.50	–
Grade H	0.10- 0.23	0.87-1.41	0.025	0.025	0.13- 0.37	0.27- 0.73	0.36-0.69	0.17-0.33	0.0005 min	0.02-0.09	0.11max	–	–	–
Grade P	0.10- 0.23	0.40-0.78	0.025	0.025	0.18- 0.37	1.15- 1.55	0.79-1.26	0.41-0.64	0.001- 0.005	–	0.11max	–	–	–
Grade Q	0.12- 0.23	0.87-1.41	0.025	0.025	0.13- 0.37	1.15- 1.55	0.94-1.56	0.36-0.64	–	0.02-0.09	–	–	–	–
Grade S	–	0.10-0.22		1.02-1.62	0.025	0.025	0.13-0.45	0.10-0.38	–	–	0.07max	–	–	0.06

ASTM A517/A517M Mechanical Properties
Sizes	Tensilestrength,min:ksi [MPa]	Yieldstrength,min:ksi [MPa]	Elongation in 2 in. [50 mm]min, %A.	Reduction of area, min, %
				Rectangularspecimens	Roundspecimens
2.50 in. [65 mm] andUnder	115-135 [795-930]	100 [690]	16	35	45
Over 2 50 to 6 in. [65 to150 mm]	105-135 1725 to930]	90 [620]	14	–	45

2.What are the characteristics of ASTM A517/A517M?

High Strength:Designed for applications requiring exceptional yield and tensile strength, especially in welded pressure vessels subjected to high stress.
Weldability:Offers good weldability with appropriate preheating and post-weld heat treatment (PWHT) to prevent cracking.
Heat Treatment:Typically quenched and tempered (Q&T) to achieve required mechanical properties.
Impact Resistance:Provides excellent toughness and impact resistance, even at low temperatures (varies by grade, e.g., Grade E offers improved low-temperature toughness).
Grade Variations:Includes grades like Grade B, Grade E, Grade F, etc., each tailored for specific environments and stress conditions.
Thickness Range:Available in various thicknesses (typically up to 150 mm or more, depending on the grade and manufacturer).

3.What is the equivalent of ASTM A517/A517M?

The equivalent grades of the ASTM A537 Class 1 Carbon Steel Plates are the DIN 19Mn5 and SPV36 standards. All these plates are produced under the watchful eye of our experienced staff.
