Pressure Vessel Steel Plate P275N Manufacture

2025-12-12 | More News

If you’re satisfied with our boilers and pressure vessel steel plate p275n, p275nh, p275nl1, p275nl2, welcome to place orders with us. As one of the best Boiler Pressure Vessel Steel Plate manufacturers and suppliers in China, we have bulk hot sale products in stock at your choice. For detailed chemical composition and free sample, contact our factory now. Competitive price and good service are offered.

EN 10028-3 P275N pressure vessel steels, as a steel specially used for pressure vessel manufacturing, occupies an important position in many engineering applications due to its excellent characteristics.

EN 10028-3 P275N pressure vessel steels is a high-quality non-alloy fine-grained steel. From the perspective of characteristics, it has a good balance of strength and toughness. When subjected to internal pressure, it can effectively resist deformation with its own strength to ensure the structural integrity of the pressure vessel; at the same time, its toughness makes it less likely to brittle fracture when facing impact or temperature changes, ensuring the safe operation of the equipment under complex working conditions.

Product Detail

Name	Boiler Steel Plate for Pressure Vessel
Standard	EN10028-3
Material	P275/P355/P460N NH NL1 NL2
Certifications	ISO/BV/SGS
Sample	Free Sample for test
Service	24 hours online
Quality	First Class
Packaging	Seaworthy Export Standard
Equivalent Standard	ASTM, AISI, ASME, DIN, BS, JIS, GB, etc.
Equivalent Grade	A516 A387 SA537 SB450 13CrMo44 15CrMoR
Product Keywords	steel grade P275N for gas industry,hot rolled steel P275N,hot rolled steel PP275NL1

P275N Chemical Composition

P275N Chemical Composition
Grade	The Element Max (%)
Grade	C	Si	Mn	P	S	Al(min)	N
P275N	0.18	0.40	0.5-1.40	0.030	0.025		0.02
	Cr	Cu	Mo	Nb	Ni	Ti	V
	0.30	0.30	0.08	0.005	0.50	0.03	0.05

P275N Mechanical Property

Grade		P275N Mechanical Property
Grade	Thickness	Yield	Tensilmie	Elongation	Impact Energy(KV J) min
P275N	mm	Min Mpa	Mpa	Min %	-20°	0°	+20°
	≤ 16	275	390-510	24	40	47	55
	16> to ≤35	275	390-510	24	40	47	55
	35> to ≤50	265	390-510	24	40	47	55
	50> to ≤70	255	390-510	24	40	47	55
	70> to ≤100	235	370-490	23	40	47	55
	100> to ≤150	235	350-470	23	40	47	55

Equivalent steel grade of P275N

Equivalent steel grade of P275N
Europe	Belgium	Germany	BS 1501	Italy	Sweden	India	Japan
		St E285	224 Gr. 400

Main Application Fields

Due to its excellent comprehensive performance, P275N steel plate is widely used in:

Boiler manufacturing: Pressure components of industrial boilers and power plant boilers
Pressure vessels: Reactors and storage tanks in the chemical, petroleum, and natural gas industries
Pipeline systems: Pressure-bearing pipelines for transporting high-temperature liquids (e.g., hot water, hot oil)
Heat exchangers: Industrial heat exchange equipment, such as the high-efficiency shell-and-tube and plate heat exchangers produced by GNEE Group
Low-temperature equipment: Pressure vessels that can operate at appropriate temperatures (-20℃)

If you want to learn about or purchase other hot rolled steel plates from GNEE, you can send an email to [email protected]. We will be very happy to serve you.

Other steel plate
Name	Material	Specification (mm)	Tons	Remark
Clad steel plate	P265GH+410,S355JR+410,A516Gr70+316, A537CL1+304L,Q235B+304L,Q345B+304, A516Gr70(NACE)+410,A537CL1+904L, A537CL1+316L,A516Gr70+304L,A537CL1+304 ,A516Gr70+410,A516Gr70+904L	2-300mm(Based plate),1-50mm(Composited plate)	/	UT, AR, TMCP.Normalized, Quenched and Tempered,Z Direction Test, Charpy V-Notch impact TestThe Third Party Test , Coated or Shot Blasting and Painting.
Low Alloy	Q345A, Q345B, Q345C, Q345D, Q345E, Q390, Q420, Q460C, ST52-3, S355J2+N, SS400, SA302GrC, S275NL, 35CrMo	6 – 350	5788.56	Normalizing, tempered ,controlled rolling, hot rolling , Hot rolling,1st inspection, 2nd inspection, 3rd inspection
Pressure Vessel Plate	Q245R, Q345R, Q370R, 16MnDR, 09MnNiDR, 15CrMoR, 14Cr1MoR, 12Cr2Mo1R, SA516Gr60, SA516Gr70, SA516Gr485, SA285, SA387Gr11, SA387Gr12, SA387Gr22, P265,P295,P355GH,Q245R(R-HIC),Q345R(R-HIC)	3 – 300	8650	Normalizing, tempered ,controlled rolling, hot rolling , Hot rolling,1st inspection, 2nd inspection, 3rd inspection
High-Strength Plate	WH785D/E,Q960D/E, Q890D/E,WH60D/E,WH70B,Q550D,Q590D,Q690D/E	8 – 120	3086.352	Quenched and tempered
Wear-Resistant Plate	NM360, NM400, NM450, NM500	6 – 150	3866.297	Quenched and tempered
Bridge Plate	Q235qC, Q345qC, Q370qC, Q420qC, Q345qDNH, Q370qDNH, A709 – 50F – 2, A709 – 50T – 2	8 – 200	2853.621	Hot rolling, normalized ,hot rolling controlled rolling, quenched and tempered + toughness and brittleness
