SA387 Gr.11 Cl.2 Medium-Temperature Pressure Vessel Steel Plate

SA387 Grade 11 Class 2 is a type of alloy steel plate, specifically a chrome-molybdenum steel, used in pressure vessels and other applications where high temperatures and pressures are encountered. It is known for its resistance to high temperatures and good corrosion resistance.

Chat Now

Send Inquiry

Product Description

1.What is the chemical composition of SA 387 GR 11 CLASS2?

Chemical Composition (Weight %)

Element	Standard Requirement (ASTM A387)	Typical Value Range
Carbon (C)	0.05 – 0.17% (max)	0.10 – 0.15%
Manganese (Mn)	0.40 – 0.65% (max)	0.45 – 0.60%
Phosphorus (P)	0.025% (max)	≤ 0.020%
Sulfur (S)	0.025% (max)	≤ 0.015%
Silicon (Si)	0.50 – 0.80%	0.55 – 0.75%
Chromium (Cr)	1.00 – 1.50%	1.10 – 1.40%
Molybdenum (Mo)	0.45 – 0.65%	0.50 – 0.60%

2.What is the difference between SA 516 GR 70 and SA 387 GR 11 CLASS2?

                                                         Material Type & Application

Property	SA 516 Gr. 70	SA 387 Gr. 11 Class 2
Material Type	Carbon steel plate	Chromium-molybdenum (Cr-Mo) alloy steel
Primary Use	Moderate-temperature pressure vessels (e.g., storage tanks, boilers)	High-temperature & high-pressure service (e.g., refinery reactors, power plants)
Service Temp.	Up to ~350°C (650°F)	Up to ~595°C (1100°F)
Corrosion Resistance	Standard (not for H₂S or acidic environments unless specially treated)	Better resistance to hyd

3.What is SA387 grade 11 class 2 material?

SA387 grade 11 CL. 2 Plate is a pressure vessel grade steel plate that is used in high-temperature applications. It is made of a chrome-moly alloy that contains molybdenum and chromium.

4.What is Sa 387 gr 11 cl 2 equivalent to?

The Sa 387 Gr 11 Cl 2 Equivalent Material is the SA387-11-2 of the ASME and ASTM standard. With similar chromium, molybdenum, and chemical content the, Sa 387 Gr 11 Cl 1 Equivalent Material of the BS 621B exhibits identical properties.
