P355GH for Pressure Vessel Steel

EN10028-2 P355GH refers to a specific grade of pressure vessel steel, as defined by the EN 10028-2 standard. It's a normalized steel, meaning it's been heat-treated to ensure a specific microstructure for enhanced strength and weldability. P355GH is particularly suited for applications involving elevated temperatures, making it ideal for pressure vessels, boilers, and heat exchangers in industries like petrochemicals.

Chat Now

Send Inquiry

Product Description

1.What are the chemical composition of EN10028-2 P355GH for Pressure Vessel Steel?

Element	% by mass	Element	% by mass
Carbon (C)	≤0.16	Silicon (Si)	≤0.35
Manganese (Mn)	0.60 to 1.20	Phosphorous (P) (max)	0.025
Sulphur (S) (max)	0.015	Aluminium (Al)	≤0.020
Nitrogen (N)	≤0.012	Chromium (Cr)	≤0.30
Copper (Cu)	≤0.30	Molybdenum (Mo)	≤0.08
Niobium (Nb)	≤0.020	Nickel (Ni)	≤0.30
Titanium (Ti) (max)	0.03	Vanadium (Vi)	≤0.02

2.What is EN10028-2 P355GH material grade?

P355gh is a pressure vessel grade of steel which is extensively used in the petrochemical industry. They are ideal for good performance in elevated temperature conditions.

3.What is the equivalent of EN10028-2 P355GH?

P355GH pressure vessel steel is an equivalent to ASTM A516 Grade 70 and ASME SA516 Grade 70. Widely used throughout the petrochemical industry, P355GH is a pressure vessel steel grade as specified under the Euro Norm standard (EN10028) which has superseded British Standard and DIN standard equivalents.

4.What is the difference between EN10028-2 P355GH and EN10028-3 P355NH?
