Pressure Vessel-Grade A537 Class 3 Plate

ASTM A537 Class 3 is a specification for heat-treated, carbon-manganese-silicon steel plates used in pressure vessels. These plates are quenched and tempered to achieve specific mechanical properties. They are typically used in fusion welded pressure vessels and structures.

Chat Now

Send Inquiry

Product Description

1.What chemical components are contained in Pressure Vessel-Grade A537 Class 3 Plate?

A537 class 3 Chemical Composition
Grade	The Element Max(%)
Grade	C	Mn	P	S	Si	Cu	Ni	Cr	Mo
A537 class 3	0.24	0.92-1.72	0.035	0.035	0.13-0.55	0.38	0.28	0.29	0.09

2.What are the differences between A537 Class 3 and A537 Class 2?

Comparison Item	A537 Class 3	A537 Class 2
Heat Treatment	Quenched & Tempered (Q&T)	Quenched & Tempered (Q&T)
Yield Strength	≥450 MPa (65 ksi)	≥415 MPa (60 ksi)
Tensile Strength	550-690 MPa (80-100 ksi)	550-690 MPa (80-100 ksi)
Elongation	≥18% (in 50mm gauge length)	≥20% (in 50mm gauge length)
Charpy Impact	≥27J @ -40°C (extendable to -60°C)	≥27J @ -30°C

3.How is the low-temperature toughness of Class 3? Is it suitable for LNG storage tanks?

Impact toughness requirement: Typical value ≥27J @ -40°C (can be customized to -60°C)
LNG applicability: Yes, but requires nickel microalloying (e.g., 0.5% Ni addition) to enhance toughness below -100°C.
