A387 Grade 22 Class 2 for Boiler Steel Plate

The A387 Grade 22 Class 2 – a grade of chromium-molybdenum alloy – is mainly intended for use in pressure vessels and welded boilers, which are designed for use in elevated temperature service.

Chat Now

Send Inquiry

Product Description

1.What are the chemical composition of A387 Grade 22 Class2?

A387 Gr.22CL.2Chemical Composition
Grade	The Element Max(%)
Grade	C	Si	Mn	P	S	Cr	Mo
A387 Gr.22 Cl.2	0.04-0.15	0.50	0.30-0.60	0.035	0.035	1.88-2.62	0.85-1.15

2.What are the advantages of A387 Grade 22 Class 2?

Good Corrosion Resistance:Exhibits excellent performance in medium-temperature hydrogen-rich environments, effectively preventing various corrosion phenomena.

High Strength:As a steel plate for pressure vessels, its strength meets the service requirements of high-pressure vessels.

Low Temper Embrittlement:After appropriate heat treatment, it has low temper embrittlement, enhancing the toughness and reliability of the steel plate.

3.What are the differences between A387 Grade 22 Class 2 and other chromium-molybdenum alloy materials?

Material	A387 Grade 11 Class 2 (1.25Cr-0.5Mo)	A387 Grade 22 Class 2 (2.25Cr-1Mo)	A387 Grade 91 Class 2 (9Cr-1Mo-V-Nb)
Chromium Content	1.25%	2.25%	9% (with V/Nb microalloying)
High-Temperature Strength	Good up to ~540°C	Excellent up to ~593°C	Superior up to ~650°C
Creep Resistance	Moderate	High (due to higher Mo and Cr)	Ultra-high (fine-grained martensite + precipitates)
Oxidation Resistance	Moderate in steam/hydrogen	Strong resistance to H₂S/CO₂ corrosion	Best for severe oxidation (e.g., coal gasification)
Typical Applications	Steam boilers, heat exchangers	Petrochemical hydrogenation reactors	Ultra-supercritical power plant pipelines
